本噴砂機適用于10-490mm直徑的常見零部件的國內外面上diy手工實操噴砂高空作業,清掉外面上的污跡、面上噴砂除銹、面上強化木紋地板、從而提高很糙度、出掉面上地應力等。(舉例子:電飯煲、杯具、不粘鍋、手機手機機殼、電腦上機殼、水輪、圓鋸片……)可按業主的要求制作廠單辦公車間工作臺或雙辦公車間工作臺。
The sandblasting machines apply to 10-490 mm diameter of of all kinds of the internal and external surfaces of the manual operation sandblast homework, remove the dirt, surface derusting appearance, surface strengthening and improving roughness, removing surface stress, etc. (for example: electric meal bao, cup with, titanium, cell phone casing, computer shell, impeller, saw blades, etc) make single or double position according to customers' special requirements.
◆核心技術工藝參數設置 Main technical parameters
|
產品材質 Model |
STR-A1500型12槍圓筒換向式 |
STR-A1600型八槍圓輪回升式 |
STR-A1600型十四槍圓輪退回式 |
|
機床大小 Complete machine size(mm) |
1500×2160×3000 |
1600×1800×2500 |
2200×2400×3000 |
|
運作艙尺寸 Working class size(mm) |
Φ1400 |
Φ1500 |
Φ2000 |
|
除塵處理箱寸尺 Dedust box sizes(mm) |
1000×1200×2500 |
1000×1200×2500 |
1400×1400×2500 |
|
小轉盤數 The small turntable for |
16個 |
8個 |
8個 |
|
噴槍數 Gun number |
12把 |
8把 |
14把 |
|
交流電源 Power |
380V三相電電 |
380V三相四線制電 |
380V380V電 |
|
照明 Floodlight |
2盞防暴燈 |
2盞防震燈 |
2盞防震燈 |
|
絲機載重量 Machine weight |
800kg |
750kg |
800kg |
